Flexible drag chain cable, bending resistant cable, high flexible drag chain cable, high flexible drag chain cable, drag chain cable manufacturer, bending resistant cable, Shanghai Kebang special cable factory, application advantages of flexible drag chain cable: patent certification, RoHS and EU CE certification
Mobile application: laying stroke: & lt; 100m, acceleration 20m / S2, moving speed 5m / s, bending life: 50 times / min, & gt; 10 million times
Technical parameters of flexible drag chain cable: working voltage: uo / u, 300 / 500V, 450 / 750V, 600 / 1000V, test voltage: 3500v 5min bending radius: fixed installation: 5x cable outer diameter; Mobile installation: 7.5x cable outer diameter service temperature: fixed installation: - 45 ° C to + 100C; Mobile installation: - 40 ° C to + 90C flame retardant characteristics: comply with IEC 60332-1-2 flexible drag chain cable product structure: Conductor: multi strand fine twisted anti bending oxygen free fine copper wire conductor, comply with GB / t3956-2008 standard class 6 insulation: high mechanical performance insulation TPEE material
Core identification: sectional area & lt; 0.5mm2 is identified by color separation or dot; 20.5mm black number and white number, and one core wire can be used with yellow / Green grounding wire (optional)
Core wire structure: excellent pitch stranded cable, layered or grouped stranded gap with optimized structure, polyester fiber filled inner protective material: suitable for extrusion and fixation of high mechanical performance TPU compound of drag chain cable
Shielding structure: high density tinned copper mesh woven shielding, density 280%
Outer protective material: high mechanical performance pur mixture suitable for drag chain cable
Sheath color: black or gray
Application scope of flexible drag chain cable products: flexible drag chain cable is widely used for installation under continuous reciprocating motion, especially in frequent bending occasions in industrial use environment, such as drag chain of modern mechanical standard parts, logistics system, control system, mechanical automation system, etc; CNC machine tools, wood and stone machinery, glass and door and window machinery, injection molding machine, construction machinery, heavy machinery factory, automobile manufacturing, lifting and transportation equipment, automatic warehouse and other occasions; The product has a low viscosity surface, does not adhere to other objects within the service temperature range, and has excellent anti-interference, anti shallow water, oil resistance, flame retardant, environmental protection, wear resistance, anti ultraviolet and other excellent properties. At the same time, it can withstand general external mechanical forces.
